Brand new 39" width circket pitch roller.
Tiger Brand from Ha-Ko Group, India Latest Technology 100% ELECTRIC 1.8 Ton EV battery powered Cricket Ground Roller

Water Ballast to Weight Increase - 250 Litres to increase weight

Rolling Diameter: 600mm
Rolling Width: 1000mm
Speed (0-5kmph) Forward and Reverse
Benefits -
• Lower running costs
• Very Low maintenance costs.
• 3 years warranty on manufacturing Defect.

MODEL HK - EV 1800
Product certification Intellectual Property, Patent application no- 202521020337, yr 2023

ELECTRIC MOTOR - 3phase BLDC brushless direct current. With soft starting technology.
STEERING - Mechanical gearbox
TRANSMISSION -Torque convertor, Reduction Gearbox, with USA brand imported electronic controller driver
Speed control -Electronically controlled FNR Hand lever accelerator, fixed detained type at any desired speed
SPEED - Km/h Variable 0 – 5, controlled by Hand Lever for slow to fast rolling.
OVERALL HEIGHT - with Canopy / wout canopy mm 1900 / 900
OVERALL LENGTH - mm 2150
OVERALL WIDTH - mm 1000
STARTING - Electric key switch with forward and reverse mechanical lever
Battery - ARAI test certificate and BIS approved, HK brand Lithium – ion 6.8kw with wireless mobile Android Application for battery health check.
Seat - High comfort cushion seat with folding and slider for leg room adjustment. With ‘No Operator ON Seat’ safety switch sensor.
Head light- 12v led
Roof - FRP sheet
Brake - Foot operated Hydraulic / mechanical piston, disk braking with slow stopping, with auto motor power cut-off sensor switch for safety.
Charging time- 6 hours
charger - 230VAC, 30 amps fast charger, with auto off and indicator light
dashboard- Battery health meter, changeover switch, headlight switch, ON/OFF keyswitch
safety- Over heat auto cutoff controller, brake switch, underseat cutoff sensor, battery BMS with android mobile output.
Running time / usage 6 to 7 hours as per the load (soil condition) on single 100% (full) charge
Warranty -

We offer standard 1 years cover against manufacturing defect on Motor and battery.
One year cover –
• Controller / driver.
• Electrical wiring harness.
• Charger.
• Steering assembly
• Transmission gearbox
• Fabrication faults
Not covered –
• Consumable and wear tear parts are not covered under warranty.
• Fault related to electrical current fluctuation.
• User operating error.
• Brake pads
• Gears, Rubber belts and chain
• tie rod & bearings
• damages due to natural calamities
• accidents- loading, unloading
• Unauthorised third party technician or support.
• Battery not charged / completely discharged to 0%
• Wrong charger used for charging
• Damage of Wiring disconnected or corroded

whatsapp - 00919867279028 / 00447448660818
